Small LCD screen 2.4-inch IPS type 240 * 320 resolution MCU interface ST7789P3 driver IC instrument display terminal
Product Overview
1.1 Description
The YT024B023-v02 is a color active matrix Thin Film Transistor (TFT) Liquid Crystal Display (LCD) that uses amorphous silicon(a-Si) TFT as a switching device. This module has a single 2.4 inches diagonally measured active area with QVGA resolutions( 240 horizontal by 320vertical pixel array) . Each pixel is divided into RED, GREEN, BLUE dots which are arranged in vertical stripe and this module can display 262K colors. The TFT-LCD panel used for this module is adapted for a low reflection and higher color type.
1.2 Feature
-ADS type for main TFT-LCD panel
-Structure COG+FPC+BL
-Full, Normal (Still), Partial, Sleep, Standby mode are available
1.3 Application
-Display terminals for cellular phone
General Specifications
| No. | Ltem | Specification | Unit | Remark |
| 1 | LCD Size | 2.4 | inch | - |
| 2 | Panel TYpe | a-Si TFT active matrix | - | - |
| 3 | Resolution | 240 x (RGB) x 320 | pixel | - |
| 4 | Display Mode | Normally Black,Transmissive | - | - |
| 5 | Display Number of Colors | 262K color | - | - |
| 6 | Viewing Direction | ALL o′clock | (°) | Note |
| 7 | Contrast Ratio | 1200:1 | - | - |
| 8 | Luminance | 300 | cd/m2 | - |
| 9 | Module Size | 42.72(W ) x 60.26(L) x 2.3(T) | mm | Note |
| 10 | Active Area | 36.72(W) x 48.96(L) | mm | Note |
| 11 | Pixel Pitch | 0.51(W ) x 0.153(L) | mm | - |
| 12 | Back Light | 4 LEDs White | - | - |
| 13 | weight | 22 | g | - |
| 14 | Power Supply Voltage | VDD=2.3~3.3 | V | - |
| 15 | Respone time | 12 | ms | - |
| 16 | Interface | 8BIT MCU | - | - |
| 17 | Operating Temperature | -20~70 | ℃ | - |
| 18 | Storage Temperature | -30~80 | ℃ | - |
