IP65 7" 16.7M Color HMI Touch Screen With Ethernet Port

Product Categories

ShenZhen Adia Techology CO.,LTD

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Name: IP65 7quot 167M Color HMI Touch Screen With Ethernet Port
Brand: adia
Price: 60 USD

Brand Name : adia

Model Number : YD070Z11SL40GK

Place of Origin : china

MOQ : 10pcs

Price : 60USD

Supply Ability : 1KK/M

Delivery Time : 20-25

Packaging Details : 50cm*50cm*60cm

HTMI : LCM display,Tempered glass led writing board,holographic projector laser christmas outdoor,a-Si TFT-LCD,touch screen

Touch : Customized Size

Working temperature : -40 degree - +65 degree

Warranty : 1-3 Years

Product name : TFT Module Screen

Size : 7''

Contact Now

Parameter summary Display: 7 "1024 * 600 24bit 16.7M color 7" TFT Color Touch Screen HMI with Ethernet Port

1.1. Parameter summary

1) Display: 7 "1024 * 600 24bit 16.7M color

2)CPU:SuperV Z11s ARMCortex-A7 1.2GHz 512Mbit DDR2

3) Storage: 128Mbit norflash

4) Power supply: DC 5V, 600mA

5) Storage temperature: - 30 ~ 80 ℃

6) Working temperature: - 20 ~ 70 ℃

7) Display brightness: 450cd / M

8) Touch screen: gt911 capacitive touch p + G material

Specifications	Items	SK-070FS; SK-070HS
Display	Dimension	7" ( Length x Width = 16:9 )
	Resolution	800 x 480
	Touch Panel	4- wire high precision touch panel
	Display Color	266,144
	Backlight Unit	LED
	Contrast	450:1
	Brightness	450cd/sqm
SD Card		Yes / Yes
Memory		128M/FLASH + 64M DDR
CPU		32-bit 600MHz A8
Protection Grade		IP 65 Front Panel
Housing Material		Engineering Plastics: ABS+PC
Power Supply	Power Supply	DC24V(+/-15%)
Power Supply	Power Consumption	6w
Interface	Serial Interface	COM1: RS232/422/485 and COM2: RS232/422/485
	USB Download Port	Yes / Yes
	USB	Yes / Yes
	RJ 45	Yes / Yes
Environment	Operation Environment Temperature	~10 to 65C
	Operation Environment Humidity	10 ~ 90% RH
	Anti-Vibration	10-25Hz( XYZ direction 2G/30 minute)
Mechanical	Dimension (widthheightdepth mm)	AS: 228 x 154 x 41mm BS: 203 x 145 x 40mm
	Cut-out (width*height mm)	AS: 211 x 145mm BS: 192 x 138mm
	Weight	1.5kg

IP65 7" 16.7M Color HMI Touch Screen With Ethernet Port
